After slitter blades are resharpened, the edge condition directly determines the quality and life of the next slitting cycle. Many users receive the resharpened blades, only look at whether they are "bright" or "sharp," and hastily install them for use. As a result, cutting burrs are large, life is short, and even chipping occurs. Mingbai Mechanical Tool Technology Co., Ltd., combining years of resharpening and inspection experience, summarizes a set of quick inspection methods that can be performed on-site to help you judge whether the edge meets standards before installation. 1. Why Must Inspection Be Done After Resharpening? The resharpening process removes the worn layer but may introduce new problems: grinding burn causing hardness reduction, angle deviation causing cutting force changes, and micro-chipping of the edge causing early failure. If installed without inspection, at best the cutting quality fails to meet standards; at worst, the blade shaft and equipment are damaged. Therefore, inspection after resharpening is the first line of defense for ensuring slitting quality. 2. Five Core Items for Quick Inspection 1. Visual inspection — check whether the edge dark line is uniform Place the reground slitter blades for metal cutting under strong light and observe the edge dark line. A qualified product should show a fine, uniform, continuous dark line, with no white edge, no chipping, and no breaks. If the dark line varies in width or shows bright reflections, it indicates uneven edge grinding or micro-chipping, requiring rework. 2. Edge angle inspection — use an angle gauge or profilometer The edge angle directly affects cutting resistance. On-site, use a dedicated angle gauge against the edge to measure, with deviation required to be ≤±0.5°. For precision slitting circular blades, a portable profilometer is recommended to measure whether the wedge angle and clearance angle match the drawing. If the angle is too large, cutting resistance increases; if too small, edge strength is insufficient. 3. Edge radius inspection — judge whether passivation is appropriate After resharpening, micro-passivation is usually required to eliminate microscopic defects. Observe the edge with a magnifying glass or microscope. The edge radius of high-speed rotary slitter blades should be controlled between R0.005-0.010mm. If the edge is too sharp (R<0.003mm), chipping is likely; if over-passivated (R>0.02mm), cutting resistance increases and burrs increase. 4. Hardness spot check — confirm no grinding annealing Grinding burn is the most common problem after resharpening. Use a portable Leeb hardness tester to spot check 3 points near the edge and compare with the original hardness; the drop should not exceed HRC2. If hardness drops significantly, it indicates insufficient cooling during grinding, causing secondary tempering, and the life of wear-resistant alloy blades for cutting will be greatly shortened. 5. Runout inspection — ensure installation accuracy Install the blade on a standard blade shaft and use a dial indicator to measure radial runout and axial runout. The radial runout of custom slitter blades for industrial use should be ≤0.005mm, and axial runout ≤0.008mm. If runout exceeds tolerance, periodic burrs will occur during cutting and edge wear will accelerate. 3. On-Site Quick Inspection Tool List Strong flashlight or desk lamp 10x magnifying glass or portable microscope Dedicated edge angle gauge Portable Leeb hardness tester Dial indicator and magnetic base Standard blade shaft or inspection mandrel 4. Judgment Criteria and Handling Recommendations Qualified: uniform dark line, angle deviation ≤±0.5°, edge radius within range, hardness drop ≤HRC2, runout within tolerance. Can be directly installed and used. Unqualified: if any item exceeds tolerance, it should be reworked or scrapped. If hardness drop exceeds tolerance, re-heat treatment is required; if angle or radius deviates, regrinding can correct it; if runout exceeds tolerance, check the blade shaft or blade bore. 5. Mingbai Technology's Resharpening Inspection Service Mingbai Mechanical Tool Technology Co., Ltd. provides one-stop resharpening and inspection services for high-precision circular blades for slitting. Each resharpened blade undergoes five inspections: appearance, angle, radius, hardness, and runout, with an inspection report attached. We promise: the edge quality after resharpening reaches over 95% of a new blade; if not up to standard, free rework. Conclusion Resharpened slitter blades cannot be judged only by "whether they are sharp." Instead, quick inspection should be done through five items: appearance, angle, radius, hardness, and runout. Mastering this method allows you to screen out unqualified blades before installation and avoid production accidents. Mingbai Technology is willing to safeguard your slitting quality with professional resharpening inspection services.   FAQ : Q1: After resharpening, the edge has slight white edges. Can it still be used?A: Slight white edges may be grinding marks and do not affect use. However, if the white edges are obvious and intermittent, it indicates micro-chipping on the edge, and it should be reground before use. Q2: Without a profilometer, how can I quickly judge the edge angle?A: Use a dedicated angle gauge against the edge, or observe the edge bevel ratio with a magnifying glass. Experienced technicians can also judge by trial cutting feel. However, precise angles still require instrument measurement. Q3: How much hardness drop after resharpening is considered unqualified?A: Compared with the original hardness, a drop of more than HRC2 is judged unqualified. Hardness drop indicates grinding burn, which greatly reduces edge wear resistance and requires re-heat treatment. Q4: What should be done if runout exceeds tolerance after resharpening?A: First check whether the blade bore has burrs or damage, then check whether the blade shaft is bent. If the blade bore is the problem, rework the bore; if the blade shaft is the problem, repair the shaft. Do not force installation. Q5: What inspections are included in Mingbai Technology's resharpening service?A: It includes five items: appearance inspection, edge angle inspection, edge radius inspection, hardness spot check, and runout inspection, with an inspection report issued. If customers have special requirements, metallographic inspection and dynamic balance testing can be added. https://www.mingbaiblade.com/
