circular blades for thin sheet slitting

In slitting production, many users encounter this puzzle: the same equipment and the same set of circular blades work perfectly on 0.5mm material, but when switching to 1.5mm of the same material, problems such as burrs, tearing, and even chipping occur. They then ask: when shearing different thickness materials with circular blades, is separate customization of the edge necessary? Mingbai Mechanical Tool Technology Co., Ltd. answers: Not necessarily every time, but when the thickness difference exceeds a certain range, customization is necessary. This article provides a detailed analysis.   1. The Impact of Thickness Differences on Edge Requirements   1. Relationship between edge angle and cutting resistance   The edge angle (wedge angle) determines the sharpness and strength of the blade:   · Thin materials (<0.5mm) require a small angle (18°-22°) to maintain sharpness; otherwise, they won't cut through. · Thick materials (>2mm) require a large angle (25°-30°) to ensure edge strength; otherwise, chipping occurs.   If circular blades for thin sheet slitting are used to cut thick plates, the edge is too sharp and prone to chipping. If high-speed steel blades for thick plate shearing are used to cut thin sheets, the edge is too dull, resulting in large burrs on the cut edge.     2. Edge radius and material deformation   The edge radius (passivation value) determines the degree of extrusion when penetrating the material:   · Thin materials require an extremely small edge radius (R≤0.005mm) to minimize material deformation. · Thick materials require a slightly larger edge radius (R=0.01-0.02mm) to enhance edge impact resistance.   3. Chain reaction of gap and overlap changes   When thickness changes, the blade gap and overlap must be reset. However, if the edge design is unreasonable, even adjusting parameters will make it difficult to achieve the ideal cutting effect.     2. When Is Separate Edge Customization Necessary?   1. Thickness difference exceeds 3 times   For example, if the same equipment is used to cut both 0.3mm and 1.0mm materials, the edge angle and radius requirements are completely different. Two sets of stainless steel strip slitting circular blades should be customized.   2. Completely different material properties   Even with the same thickness, different materials (e.g., copper strip vs. stainless steel strip) have different edge requirements. Circular blades for copper strip cutting require extremely sharp, anti-adhesion edges, while alloy blades for silicon steel slitting require wear-resistant edges.   3. Different equipment rigidity   Old equipment with poor rigidity requires a duller edge to absorb impact; new equipment with sufficient rigidity can use a sharper edge. If two sets of equipment share the same high-precision custom blades, the results will inevitably differ.   3. When Is Customization Not Necessary?   · Thickness difference within ±50% (e.g., 0.8mm and 1.2mm): use a medium edge angle and adjust the gap. · Both are within the thin material range (0.3-0.8mm) or within the thick material range (1.5-3mm): only fine-tuning the gap is needed; no separate edge customization is required.     4. Mingbai Technology's "One Material, One Edge" Customization Solution   Mingbai Mechanical Tool Technology Co., Ltd. provides targeted customization services:   1. Customer provides material grade, thickness range, and equipment model. 2. Mingbai engineers calculate the optimal combination of edge angle, radius, and clearance angle. 3. Produce the corresponding custom slitter blades and attach an edge inspection report.     If the same equipment needs to cut multiple thicknesses, we can provide a "multi-edge blade set for different thicknesses" with laser marking on the blade indicating the recommended thickness to avoid misuse.   5. Case Comparison   A copper strip slitting plant used the same set of wear-resistant circular blades to cut 0.2mm and 0.8mm copper strips. Cutting 0.2mm produced smooth edges, but cutting 0.8mm resulted in severe burrs and halved blade life. Mingbai Technology customized two sets of slitting circular blades with different edges: 18° sharp edge for thin material, 25° wear-resistant edge for thick material. By switching blades when changing materials, burrs disappeared, and total blade life increased by 40%.     Conclusion   When shearing different thickness materials with circular blades, separate edge customization is not always necessary. However, when the thickness difference exceeds 3 times, material properties differ, or equipment rigidity varies significantly, customizing the edge is essential to ensure cutting quality. Mingbai Technology is committed to providing professional "one material, one edge" matching solutions, ensuring you get excellent results whether cutting thin or thick materials.   Website: www.mingbaiblade.com
